Advanced EasyPin Version

I designed a new version of EasyPin, with an adjustable pin angle (10°–90° to the scope tube) and two pin positions. For price and ordering see the product page: The new EasyPin Extra.

EasyPin Extra – Animation
EasyPin Extra – Animation

It is based on the original EasyPin model but the pin can be rotated between in a 80° range so the pointer can be used to smaller scope kobs as well, or simply can give a more comfortable reading position. The pin can be installed in two positions, depending on the actual angle.

Vertical pin position
Vertical pin position
Pin rotated by 40°
Pin rotated by 40°
Pin rotated by 40°
Pin rotated by 40°

The ring is 10 mm wide, the top is 11.5 mm above the scope tube in vertical pin position.

Side view 1
Side view 1
Top view
Top view
Side view 2
Side view 2

The new scope pointer is available in the usual three sizes: for 1″, 30 mm and 34 mm scope tubes.

EasyPin Extra 1"
EasyPin Extra 1″
EasyPin Extra 30 mm
EasyPin Extra 30 mm
EasyPin Extra 34 mm
EasyPin Extra 34 mm
