Butt Pad Kit for Scorpion Hooks

I designed a new addition to the well known Scorpion FT Hook system for those shooters who don’t use thick padded shooting jackets: the Butt Pad Kit contains two pads that can be rotated independently and add more comfort to the big centre post of the hook.

The parts have a 5mm high section of the same 24mm diameter cylinder as the main post, and have the same cogs on both sides so that they can fit into the structure of the hook. Since the two pads add 10mm to the overall height of the middle section, a 70mm long bolt is included to replace the standard 60mm main bolt. The pads have various cut-outs on the top and the sides so that they don’t clash with other elements (like the upper wing and hook) when assembled.

• Adds only 2.5mm to the centre post at the middle (longer bolt included).
• Upper part rotates without limits, even far away from the upper wing if needed.
• Lower part has to keep the main direction of the hook but still allows adjustments within a 20° range (±10° from the hook).
• Can be combined with the spacers of the Middle Extension Kit to increase the distance between the two pads.
• Compatible with all upper wing variations, long and short hooks – but not with the mini hooks.
• Compatible with the Scorpion L/H hook system, too.

Now all Scorpion FT Hooks and L/H hooks can be ordered with this Butt Pad Kit, or the kit can be bought separately on the Scorpion FT Hook Extras product page.
